LGA775 socket for Core™2 Quad/Core™2 Duo/ Pentium® Dual Core/ Celeron® Dual Core/ Celeron® 400 series processors
LGA775 socket for latest Intel® 45nm Multi-Core processors
FSB 1333/1066/800 MHz
|
|
CHIPSET
|
Intel® G41 & ICH7
North Bridge: Intel® G41
South Bridge: Intel® ICH7
|
|
GRAPHICS
|
Integrated Intel Graphics Media Accelerator X4500 (GMA X4500)
Integrated DirectX 10 graphics processor
|
|
MEMORY
|
Dual-channel DDR3 memory architecture
2 x 240-pin DDR3 DIMM socket support up to 8 GB
|
|
EXPANSION SLOT
|
1 x PCI Express x16 slot
1 x PCI Express x1 slot
1 x PCI slot
|
|
STORAGE
|
Support by Intel® ICH7
•1 x Ultra DMA133/100/66 port
•2 x Serial ATA2 devices
|
|
AUDIO
|
92HD73 6-Ch High Definition audio CODEC
|
|
LAN
|
JMC260 10/100 Fast Ethernet NIC
|
|
REAR PANEL I/O
|
1 x PS/2 keyboard & PS/2 mouse connectors
1 x D-sub(VGA)
1 x RJ45 LAN connector
1 x Audio port (Line-in, Line-out, Mic-in)
4 x USB 2.0 Ports
|
|
INTERNAL I/O CONNECTORS & HEADERS
|
1 x 24-pin ATX Power Supply connector
1 x 4pin CPU_FAN connectors
1 x IDE connector
1 x Speaker header
1 x Front panel audio header
1 x Front panel switch/LED header
1 x SPDIF out header
1 x Serial port header
2 x SATA 3Gb/s connectors
2 x USB 2.0 headers support additional 4 USB Ports
1 x Chassis intrusion header
|
